KEB COMBIVERT R6-N User Manual

Page 3.9 - 4 COMBIVERT R6-N © KEB, 2015-07
Dene CP-Parameters
CP selector (ud.15)
The CP-Parameter to be programmed in a range of 1...36 is adjusted with ud.15. CP.00 is not adjustable.
CP address (ud.16)
ud.16determinestheparameteraddressoftheparametertobedisplayed:
ud.16 CP address
Not available or not allowed pa-
rameter addresses are rejected
with "data invalid".
-1: Parameter not used
0...32767: Parameter address
CP set norm (ud.17)
Theset,theaddressingandthenormoftheparametertobedisplayedarespeciedwithud.17. The parameter
isbit-coded.Theindividualbitsaredecodedasfollows:
Denesetselectionfordirectsetaddressing
Bit 0 .. 7 determine the set selection for direct set programming i.e., all selected sets gets the same value, de-
termined by the CP-Parameter. If direct set programming (bit 8, 9) is selected, at least one set must be selected,
otherwise error message "set invalid" is displayed in the CP menue.
Bit
7 6 5 4 3 2 1 0 Value Set
0 0 0 0 0 0 0 0 0 no
-> Data invalid, if bit 8 + 9 = 0
0 0 0 0 0 0 0 1 1 0
0 0 0 0 0 0 1 0 2 1
0 0 0 0 0 1 0 0 3 0+1
... ... ...
1 1 1 1 1 1 1 1 255 All
Denesetaddressingmode
Bit8and9determinethesetaddressingmode:
Bit
8 9 Value Function
0 0 0 directsetaddressing;thedenedsetsofbit7..0arevalid
0 1 256 actual set; the actual set is displayed / edited
1 0 512
indirect set addressing, the parameter set determined by the set pointer Fr.09
is displayed / edited
1 1 768 reserved
Display standardization
Bit10..12determineshowtodisplaytheparametervalue.Withparametersud.18...21itispossibletodene
up to seven different user standardizations (below in this chapter).
