Page 3.4 - 14 COMBIVERT R6-N © KEB, 2015-07

Digital in- and outputs

do.00...do.07: Switching Conditions

Val-

Function Description

59 dig. in (ru.22) AND level

Function Switchingconditionfullledif:

AND all selected inputs are active

OR min. one selected input active

NAND min. one selected input inactive

NOR all selected inputs are inactive

The selection of inputs to be linked occurs via the comparison level param-

eters LE.00...LE.07.

Input ST RST F R I1 I2 I3 I4 IA IB IC ID

Value 1 2 4 8 16 32 64 128 256 512 1024 2048

The sum of the inputs to be queried is entered in the switching levels.

Example:IfRandI1shallbelinkedtocondition0F,value4+8+16=28.00

must be entered in LE.00.

60 dig. in (ru.22) OR level

61 dig. in (ru.22) NAND level

62 dig. in (ru.22) NOR level

63 abs.val. ANOUT2 > level

Value of ANOUT1 (amount of ru.34 „ANOUT1 post ampl. display) higher than

the switching level

65 ANOUT2 > level ANOUT1 (ru.34 „ANOUT1 post ampl. display) higher than the switching level

73 abs. val. act.power > level Amount ru.81 „active power“ > switching level

74 active power > level ru.81 „actual power“ > switching level

80 AC input current > level

Not listed values are not assigned.

Comparison level 0...7, LE.00...LE.07

Theseparametersdenethelevelsoftheswitchingconditions.

Level 0 (LE.0) applies for switching condition 0; LE.1 for switching condition 1 ... and so forth.

Hysteresis 0...7, LE. 08...LE.15

Thehysteresisinreferencetotheadjustedvalues,deneparametersLE.08...LE.15.

Hysteresis 0 (LE.08) is valid for switching level 0; LE.09 for switching level 1... etc.

3.4.16Invertconditionsforags0...7(do.08...do.15)
