CP 503/A, CP 505/A,D,K, CP 507/
A,C
Technical data
Project engineering manual V1.06
75
© KEBA 2021
12 Technical data
12.1 General
Overvoltage category: II
Equipment class: III according to EN 61010-2-201
Galvanic isolation: No
Fan:
● CP 503/x: No
● CP 505/x: No
● CP 507/x: Yes, changeable from the outside
Protective Coating:
● CP 50x/A, CP 50x/C, CP 50x/K: No
● CP 50x/D: Yes
12.2 Environmental conditions
Operating temperature:
● CP 503/x: 0 °C to +55 °C
● CP 503/x with additional output power
1)
: 0 °C to +50 °C
● CP 505/x: 0 °C to +55 °C
● CP 505/x with additional output power
1)
: 0 °C to +45 °C
● CP 507/x: 0 °C to +60 °C
Storage temperature: -40 °C to +70 °C
Relative humidity of air: 10 % to 95 % (non condensing)
Vibration resistance: According to EN 61131-2:2007
Shock resistance: According to EN 61131-2:2007
1)
For further information on the output power, see chapter "Supply".
12.3 Power supply
CP 503/x, CP 505/x
Nominal supply voltage:
24 V DC from the front (rated voltage toler-
ance 19.2 V DC to 30 V DC, in acc. with EN
61131-2)
Inrush current: Max. 10 A
Total power consumption:
● CP 503/x:
150 W
1)
165 W (with additional output power)
2)
● CP 505/x:
154 W
1)
169 W (with additional output power)
2)
