NOTES ON MAINTENANCE
Rear
wheel
brake(For
disk
brake)
Checking the brake linings
llfl
CAUTION .
The minimum lining thickness must
be
maintained
el NOTE
For your own
saf
ety, we
re
commend having
activities to the brake system carried out by
a deale
r.
_,./
- Check the thickness of the brake lining.
Minimum thickness: A = 2.0
mm
Checking the disc brake
- Visually Inspect the disc (2
).
- If the lining thickness
is
below the minimu- • Check the thickness of the disc.
m,
have the brake lining (1) replaced
by
a dealer. Minimum thickness: B =
4.
5 mm
- If the disc thickness
is
below the minimum,
have
the
di
sc (2) replaced
by
a
dealer
.
Adjusting
the
play
of
the
twist
g
rip
thrott
le co
ntro
l
Check:
- Check the throttle cable for light move-me-
nt by turning the twist grip
(1
)from closed to
open position.
- Move the handlebar to check whether the
throttle cable moves freely.
- Check whether the throttle cable
is
obstru-
cted by other parts.
- Open the twist grip throttle control until re-
sistance can be felt.
• Measure the play.
Nominal value:
A=
1-2 mm
"-,_-..,
.••·,-
Adjustment:
- Push back the protective cap (2).
• Slacken the lock nut (3) on the handlebar.
- Turn the setscrew
(4)
accordingly.
- Tighten the lock nut (3).
- Check the play.
• Push ov
er
the protective cap (2).
el NOTE
If the play cannot be corrected this way, ha-
ve
th
e scooter checked by your dealer.
