Test 402.1 — NON INV /10
Bank VAC
Inputs Open
Expected Value <none specified>
Limits <none specified>
Fault Message <none>
Description This test places the ACV front end in the non-inverting configuration.
Logic levels for this configuration are as follows:
K102: /SETK1 low, /RESETK1 high
U103: Pins 8 and 9 low
U105: Pin 9 high
The signal path is from ACIN through K102 to the plus input of U102. Re-
sistors R117 (9.9MÍ) and R146 (1.1MΩ) to form a ÷10 at the input. The feed-
back path for U102 is from the minus input through U103 (pins 6 and 7) to
node ACFE.
The signal at ACFE is divided by 10 through R110 to make ACFE/10. The
ACFE/10 signal bypasses U112 through U105 (pin 8 set LO). The signal is
then coupled across C115 to U118 which is configured for ×2 gain.
The output of U118 goes to U110 (TRMS converter) through the parallel
combination of R129, C113 and C114. The output of the TRMS converter
(OUT) is fed back through its own internal buffer. The buffer output signal
(BUFF OUT) is then labeled AC_MED. The AC_MED signal is selected at
U163 and fed to the A/D buffer (U166) through Q117. The A/D buffer is set
up for ×1 gain through U129 (/×1 low). This test is a setup phase for the next
test.
Bit patterns
Bit pattern Register
QQ
87654321
—U106—
110v0011
QQ
87654321
—U109—
11011111
QQ
87654321
—U134—
1v01000v
—U130—
10011101
QQ
87654321
—U121—
01110000
ACDC_STB
MUX_STB
IC pins: Q8=11, Q7=12, Q6=13, Q5=14, Q4=7, Q3=6, Q2=5, Q1=4
2-46 Troubleshooting
