Keithley 2000 Quick Reference Guide

25
Figure 4. Measurement event status
OR
BFL = Buffer Full BHF = Buffer Half Full BAV = Buffer Available
& = Logical AND OR = Logical OR
(B15 - B12) (B10) (B9)
BHF
(B8)
BAV
(B7) (B6)
RAV
(B5) (B4) (B3)
(B2)
LL
(B1) (B0)
Measurement Event Register
(B15 - B12)
Measurement Event Enable Register
To Measurement Summary Bit (MSB) of Status Byte Register. (See Figure 6).
&
&
(B15 - B12) (B10) (B9) (B8) (B7) (B6)
RAV
(B5) (B4) (B3)
(B2)
LL
(B1) (B0)
Measurement Condition Register
BFL
HL
ROF
BFL
ROF
&
&
&
BHF BAV
HL
&
&
(B10) (B9)
BHF
(B8)
BAV
(B7) (B6)
RAV
(B5)
(B4) (B3)
(B2)
LL
(B1) (B0)
BFL ROFHL
RAV = Reading Available
HL = High Limit LL = Low Limit ROF = Reading Overflow
(B11)
(B11) (B11)
2000-903-01A Page 25 Thursday, December 23, 1999 7:52 AM

Keithley 2000 Specifications

General

Digits	6.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Connectivity	IEEE-488 (GPIB)
Display Type	VFD
