Keithley 2000 Quick Reference Guide

6
Front Panel
Operation Summary
Power-on defaults
Power-on defaults are those settings the instrument
assumes when it is turned on. The Model 2000 offers
two choices for the settings: user or factory. With user,
the instrument will power-on to the last configuration
that you saved. With factory, the instrument will power
on to the factory default settings.
To store a user configuration in memory:
1. Configure the instrument as desired for USER
default.
2. Press SHIFT and then SAVE.
3. Use the ▲ and ▼ keys to select YES or NO.
Note: Select NO if you do not wish to change the
last configuration that you saved.
4. Press ENTER.
To restore factory or user settings:
1. Press SHIFT and then SETUP.
2. Use the ▲ and ▼ keys to select FACTory or USER.
3. Press ENTER.
NOTE: Factory default settings are listed in Table 2.
Instrument connections
Basic connections for Model 2000 measurements are
shown in Figure 1. These drawings show connections to
the front panel terminals (INPUTS switch in the FRONT
position). If using the rear panel terminals, place the
2000-903-01A Page 6 Thursday, December 23, 1999 7:52 AM

Keithley 2000 Specifications

General

Digits	6.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Connectivity	IEEE-488 (GPIB)
Display Type	VFD
