DCV PEAK SPIKES MEASUREMENT
REPETITIVE SPIKES ACCURACY
1
90 Days,
±
2
°
C from last AC self-cal
±
(% of reading+% of range)
TEMPERATURE COEFFICIENT
1kHz– 10kHz– 30kHz– 50kHz– 100kHz– 300kHz– 500kHz– 750kHz–
±
(% of reading+% of range)/
°
C
RANGE 0–1kHz
4
10kHz 30kHz 50kHz 100kHz 300kHz 500kHz 750kHz 1MHz Outside T
CAL
±
2
°
C
200 mV 0.08+0.7 0.08+0.7 0.1 +0.7 0.15+0.7 0.25+0.7 1.0+0.7 2.5+0.7 5.5+0.7 9+0.7 0.002+0.03
2 V 0.08+0.3 0.08+0.3 0.1 +0.3 0.15+0.3 0.25+0.3 1.0+0.3 2.5+0.3 5.5+0.3 9+0.3 0.002+0.03
20 V 0.09+0.7 0.1 +0.7 0.12+0.7 0.17+0.7 0.25+0.7 1.0+0.7 2.5+0.7 5.5+0.7 9+0.7 0.004+0.03
200 V
3
0.09+0.3 0.1 +0.3 0.12+0.3 0.17+0.3 0.25+0.3 1.0+0.3
2
2.5+0.3
2
5.5+0.3
2
9+0.3
2
0.004+0.03
1000 V
3
0.1 +0.6 0.13+0.6 0.16+0.6 0.25+0.6
2
0.5 +0.6
2
0.01 +0.02
Max. % of Range
±
125%
±
125%
±
125%
±
125%
±
125%
±
125%
±
125%
±
100%
±
75%
REPETITIVE SPIKES ACCURACY
1
1 or 2 Years, T
CAL
±
5
°
C
±
(% of reading+% of range)
TEMPERATURE COEFFICIENT
1kHz– 10kHz– 30kHz– 50kHz– 100kHz– 300kHz– 500kHz– 750kHz–
±
(% of reading+% of range)/
°
C
RANGE 0–1kHz
4
10kHz 30kHz 50kHz 100kHz 300kHz 500kHz 750kHz 1MHz Outside T
CAL
±
5
°
C
200 mV 0.08+0.7 0.09+0.7 0.1 +0.7 0.15+0.7 0.25+0.7 1.0+0.7 2.5+0.7 5.5+0.7 9+0.7 0.002+0.03
2 V 0.08+0.3 0.09+0.3 0.1 +0.3 0.15+0.3 0.25+0.3 1.0+0.3 2.5+0.3 5.5+0.3 9+0.3 0.002+0.03
20 V 0.1 +0.7 0.11+0.7 0.14+0.7 0.19+0.7 0.25+0.7 1.0+0.7 2.5+0.7 5.5+0.7 9+0.7 0.004+0.03
200 V
3
0.1 +0.3 0.11+0.3 0.14+0.3 0.19+0.3 0.25+0.3 1.0+0.3
2
2.5+0.3
2
5.5+0.3
2
9+0.3
2
0.004+0.03
1000 V
3
0.12+0.6 0.16+0.6 0.2 +0.6 0.25+0.6
2
0.5 +0.6
2
0.01 +0.02
Max. % of Range
±
125%
±
125%
±
125%
±
125%
±
125%
±
125%
±
125%
±
100%
±
75%
DEFAULT MEASUREMENT RESOLUTION: 3
1
⁄
2
digits.
MAXIMUM INPUT:
±
1100V peak value, 2×10
7
V•Hz (for inputs above 20V).
NON-REPETITIVE SPIKES: 10% of range per
µ
s typical slew rate.
SPIKE WIDTH: Specifications apply for spikes
≥
1
µ
s.
RANGE CONTROL: In Multiple Display mode, voltage range is the same as
DCV range.
SPIKES MEASUREMENT WINDOW: Default is 100ms per reading (settable from
0.1 to 9.9s in Primary Display mode).
INPUT CHARACTERISTICS: Same as ACV input characteristics.
SPIKES DISPLAY: Access as multiple display on DC Volts. First option presents
positive peak spikes and highest spike since reset. Second option presents
negative spikes and lowest spike. Highest and lowest spike can be reset by
pressing DCV function button. Third option displays the maximum and
minimum levels of the input signal. Spikes displays are also available
through CONFIG-ACV-ACTYPE as primary displays.
DCV PEAK SPIKES NOTES
1. Specifications apply for 10-reading digital filter. If no filter is used, add 0.25% of range
typical uncertainty.
2. Typical values.
3. Add 0.001% of reading × (VIN/100V)
2
additional uncertainty for inputs above 100V.
4. Specifications assume AC+DC coupling for frequencies below 200Hz. Below 20Hz add
0.1% of reading additional uncertainty.
AC VOLTS
AC magnitude: RMS or Average. Peak and Crest Factor measurements also available.
ACV INPUT CHARACTERISTICS
TEMPERATURE COEFFICIENT
2
RMS PEAK FULL SCALE DEFAULT
±
(% of reading + % of range) /
°
C
RANGE INPUT RMS RESOLUTION RESOLUTION INPUT IMPEDANCE Outside T
CAL
±
5
°
C
200 mV 1 V 210.0000 100 nV 1
µ
V1M
Ω
±
2% with <140pF 0.004 + 0.001
2 V 8V 2.100000 1
µ
V 10
µ
V1M
Ω
±
2% with <140pF 0.004 + 0.001
20 V 100 V 21.00000 10
µ
V 100
µ
V1M
Ω
±
2% with <140pF 0.006 + 0.001
200 V 800 V 210.0000 100
µ
V 1 mV 1M
Ω
±
2% with <140pF 0.006 + 0.001
750 V 1100 V 775.000 1 mV 10 mV 1M
Ω
±
2% with <140pF 0.012 + 0.001
AC VOLTAGE UNCERTAINTY =
±
[ (% of reading) × (measured value) + (% of range ) × (range used) ] / 100.
PPM ACCURACY = (% accuracy) × 10,000.
0.015% OF RANGE = 30 counts for ranges up to 200V and 113 counts on 750V range at 5
1
⁄
2
digits.
LOW FREQUENCY MODE RMS
1
90 Days,
±
2
°
C from last AC self-cal, for 1% to 100% of range
3
±
(% of reading + % of range)
RANGE 1–10Hz
5
10–50Hz 50–100Hz 0.1–2kHz 2–10kHz 10–30kHz 30–50kHz 50–100kHz 100–200kHz 0.2–1MHz 1–2MHz
200 mV 0.09+0.015 0.04+0.015 0.03+0.015 0.03+0.015 0.03+0.015 0.035+0.015 0.05+0.015 0.17+0.015 0.5+0.025 2+0.1 5+0.2
2 V 0.09+0.015 0.04+0.015 0.03+0.015 0.03+0.015 0.03+0.015 0.035+0.015 0.05+0.015 0.17+0.015 0.5+0.025 2+0.1 5+0.2
20 V 0.1 +0.015 0.05+0.015 0.04+0.015 0.04+0.015 0.06+0.015 0.08 +0.015 0.1 +0.015 0.17+0.015 0.5+0.025 4+0.2 7+0.2
5
200 V
4
0.1 +0.015 0.05+0.015 0.04+0.015 0.04+0.015 0.06+0.015 0.08 +0.015 0.1 +0.015 0.17+0.015 0.5+0.025
5
4+0.2
5
750 V
4
0.13+0.015 0.09+0.015 0.08+0.015 0.08+0.015 0.09+0.015 0.12 +0.015 0.15+0.015
5
0.5 +0.015
5
LOW FREQUENCY MODE RMS
1
1 or 2 Years, T
CAL
±
5
°
C for 1% to 100% of range
3
±
(% of reading + % of range)
RANGE 1–10Hz
5
10–50Hz 50–100Hz 0.1–2kHz 2–10kHz 10–30kHz 30–50kHz 50–100kHz 100–200kHz 0.2–1MHz 1–2MHz
200 mV 0.11+0.015 0.06+0.015 0.05+0.015 0.05+0.015 0.05 +0.015 0.05+0.015 0.06+0.015 0.17+0.015 0.5+0.025 2+0.1 5+0.2
2 V 0.11+0.015 0.06+0.015 0.05+0.015 0.05+0.015 0.05 +0.015 0.05+0.015 0.06+0.015 0.17+0.015 0.5+0.025 2+0.1 5+0.2
20 V 0.12+0.015 0.07+0.015 0.06+0.015 0.06+0.015 0.085+0.015 0.12+0.015 0.13+0.015 0.17+0.015 0.5+0.025 4+0.2 7+0.2
5
200 V
4
0.12+0.015 0.07+0.015 0.06+0.015 0.06+0.015 0.085+0.015 0.12+0.015 0.13+0.015 0.17+0.015 0.5+0.025
5
4+0.2
5
750 V
4
0.15+0.015 0.11+0.015 0.1 +0.015 0.1 +0.015 0.13 +0.015 0.18+0.015 0.22+0.015
5
0.5 +0.015
5
