A-5
AC VOLTS (cont’d)
NORMAL MODE RMS
1
90 Days,
±
2
°
C from last AC self-cal for 1% to 100% of range
3
±
(% of reading + % of range)
RANGE 20–50Hz 50–100Hz 0.1–2kHz 2–10kHz 10–30kHz 30–50kHz 50–100kHz 100–200kHz 0.2–1MHz 1–2MHz
200 mV 0.25+0.015 0.07+0.015 0.03+0.015 0.03+0.015 0.035+0.015 0.05+0.015 0.17+0.015 0.5+0.025 2+0.1 5+0.2
2 V 0.25+0.015 0.07+0.015 0.03+0.015 0.03+0.015 0.035+0.015 0.05+0.015 0.17+0.015 0.5+0.025 2+0.1 5+0.2
20 V 0.25+0.015 0.07+0.015 0.04+0.015 0.06+0.015 0.08 +0.015 0.1 +0.015 0.17+0.015 0.5+0.025 4+0.2 7+0.2
5
200 V
4
0.25+0.015 0.07+0.015 0.04+0.015 0.06+0.015 0.08 +0.015 0.1 +0.015 0.17+0.015 0.5+0.025
5
4+0.2
5
750 V
4
0.25+0.015 0.1 +0.015 0.08+0.015 0.09+0.015 0.12 +0.015 0.15+0.015
5
0.5 +0.015
5
NORMAL MODE RMS
1
1 or 2 Years, T
CAL
±
5
°
C for 1% to 100% of range
3
±
(% of reading + % of range)
RANGE 20–50Hz 50–100Hz 0.1–2kHz 2–10kHz 10–30kHz 30–50kHz 50–100kHz 100–200kHz 0.2–1MHz 1–2MHz
200 mV 0.25+0.015 0.08+0.015 0.05+0.015 0.05 +0.015 0.05+0.015 0.06+0.015 0.17+0.015 0.5+0.025 2+0.1 5+0.2
2 V 0.25+0.015 0.08+0.015 0.05+0.015 0.05 +0.015 0.05+0.015 0.06+0.015 0.17+0.015 0.5+0.025 2+0.1 5+0.2
20 V 0.25+0.015 0.08+0.015 0.06+0.015 0.085+0.015 0.12+0.015 0.13+0.015 0.17+0.015 0.5+0.025 4+0.2 7+0.2
5
200 V
4
0.25+0.015 0.08+0.015 0.06+0.015 0.085+0.015 0.12+0.015 0.13+0.015 0.17+0.015 0.5+0.025
5
4+0.2
5
750 V
4
0.27+0.015 0.11+0.015 0.1 +0.015 0.13 +0.015 0.18+0.015 0.22+0.015
5
0.5 +0.015
5
dB ACCURACY RMS
±
dB, 90 Days, 1 or 2 Years, T
CAL
±
5
°
C, Reference=1V, Autoranging, Low Frequency Mode, AC+DC Coupling
INPUT 1–100Hz 0.1–30kHz 30–100kHz 100–200kHz 0.2–1MHz 1–2MHz
–54 to–40 dB (2mV to 10mV) 0.230 0.225 0.236 0.355
–40 to–34 dB (10mV to 20mV) 0.036 0.031 0.041 0.088
–34 to 6 dB (20mV to 2 V) 0.023 0.018 0.028 0.066 0.265 0.630
6 to 26 dB (2 V to 20 V) 0.024 0.024 0.028 0.066 0.538 0.820
5
26 to 46 dB (20 V to 200 V) 0.024 0.024 0.028 0.066
5
0.538
5
46 to 57.8 dB (200 V to 775 V) 0.018 0.021 0.049
5
ACV READING RATES
5,6
READINGS/SECOND WITH
MEASUREMENT DEFAULT READINGS/SECOND TO MEMORY READINGS/SECOND TO IEEE-488 TIME STAMP TO IEEE-488
NPLC APERTURE BITS DIGITS Auto Zero Off Auto Zero On Auto Zero Off Auto Zero On Auto Zero Off Auto Zero On
10 167 ms (200 ms) 28 6
1
⁄
2
6 (5.1) 2 (1.7) 2 2 (1.6) 2 2 (1.5)
2 33.4 ms (40 ms) 26 5
1
⁄
2
30 (24) 9 (7.9) 28 (23) 9 (7.6) 27 (22) 9 (7.5)
1 16.7 ms (20 ms) 25 5
1
⁄
2
57 (48) 38 (35) 53 (45) 36 (33) 48 (41) 34 (30)
0.1 1.67 ms (2 ms) 21 5
1
⁄
2
136 (136) 70 (70) 122 (122) 64 (64) 98 (98) 56 (56)
0.01 167
µ
s (167
µ
s) 16 4
1
⁄
2
140 (140) 71 (71) 127 (127) 66 (66) 99 (99) 58 (58)
0.01
8
167
µ
s (167
µ
s) 16 4
1
⁄
2
2000 (2000) 2000 (2000)
AC COUPLING:
For AC only coupling, add the following % of reading:
1–10Hz 10–20Hz 20–50Hz 50–100Hz 100–200Hz
Normal Mode
(rms, average) — — 0.41 0.07 0.015
Low Frequency Mode
(rms) 0.1 0.01 0 0 0
For low frequency mode below 200Hz, specifications apply for sine wave inputs only.
AC+DC COUPLING:
For DC>20% of AC rms voltage, apply the following
additional uncertainty, multiplied by the ratio (DC/AC rms). Applies to rms
and average measurements.
RANGE % of Reading % of Range
200mV, 20V 0.05 0.1
2V, 200V, 750V 0.07 0.01
ACV CREST FACTOR MEASUREMENT
11
CREST FACTOR = Peak AC / rms AC.
CREST FACTOR RESOLUTION: 3 digits.
CREST FACTOR ACCURACY: Peak AC uncertainty + AC normal mode rms
uncertainty.
MEASUREMENT TIME: 100ms plus rms measurement time.
INPUT CHARACTERISTICS: Same as ACV input.
CREST FACTOR FREQUENCY RANGE: 20Hz – 1MHz.
CREST FACTOR DISPLAY: Access as multiple display on AC volts.
ACV PEAK VALUE MEASUREMENT
10
REPETITIVE PEAK ACCURACY,
±
(% of reading+% of range), 90 Days, 1 Year or 2 Years, T
CAL
±
5
°
C
TEMPERATURE COEFFICIENT
20Hz– 1kHz– 10kHz– 30kHz– 50kHz– 100kHz– 300kHz– 500kHz– 750kHz–
±
(% of reading+% of range)/
°
C
RANGE 1kHz
9
10kHz 30kHz 50kHz 100kHz 300kHz 500kHz 750kHz 1MHz Outside T
CAL
±
5
°
C
200 mV 0.08+0.7 0.09+0.7 0.1 +0.7 0.15+0.7 0.25+0.7 1.0+0.7 2.5+0.7 5.5+0.7 9+0.7 0.002 + 0.03
2 V 0.08+0.3 0.09+0.3 0.1 +0.3 0.15+0.3 0.25+0.3 1.0+0.3 2.5+0.3 5.5+0.3 9+0.3 0.002 + 0.03
20 V 0.1 +0.7 0.11+0.7 0.14+0.7 0.19+0.7 0.25+0.7 1.0+0.7 2.5+0.7 5.5+0.7 9+0.7 0.004 + 0.03
200 V
4
0.1 +0.3 0.11+0.3 0.14+0.3 0.19+0.3 0.25+0.3 1.0+0.3
5
2.5+0.3
5
5.5+0.3
5
9+0.3
5
0.004 + 0.03
750 V
4
0.12+0.6 0.16+0.6 0.2 +0.6 0.25+0.6
5
0.5 +0.6
5
0.01 + 0.02
Valid % of Range
7
10–400% 10–400% 10–400% 10–350% 10–350% 10–250% 10–150% 10–100% 7.5–75%
PEAK MEASUREMENT WINDOW: 100ms per reading.
MAXIMUM INPUT:
±
1100V peak, 2×10
7
V•Hz (for inputs above 20V).
DEFAULT MEASUREMENT RESOLUTION: 4 digits.
NON-REPETITIVE PEAK: 10% of range per
µ
s typical slew rate for single spikes.
PEAK WIDTH: Specifications apply for all peaks
≥
1
µ
s.
AVERAGE ACV MEASUREMENT
Normal mode rms specifications apply from 10% to 100% of range, for 20Hz–
1MHz. Add 0.025% of range for 50kHz–100kHz, 0.05% of range for 100kHz–
200kHz, and 0.5% of range for 200kHz–1MHz.
HIGH CREST FACTOR ADDITIONAL ERROR
±
(% of reading)
Applies to rms measurements.
CREST FACTOR: 1 – 2 2 – 3 3 – 4 4 – 5
ADDITIONAL ERROR: 0 0.1 0.2 0.4
