Keithley 2002 Calibration Manual

Calibration Messages
C-4
Table C-2
Calibration constants returned by :CAL:PROT:DATA? query
Cal constant Description
g1
of1
g10
of10
gfwr1
offwr1
gfwr10
offwr10
a100
a500
ofpkpos10
ofpkneg10
ofpk1
ofpkpos20
ofpkneg20
div100self
div500self
c200uaz
c2maz
c20maz
c200maz
c2az
cdivzx50
c1000vz
c200vz
c20vz
c10vz
c2vz
c200mvz
c1mr4wz
c1mrz
c200kr4wz
c200krz
c20kr4wz
c20kr4wzon
c20kr4wzoff
c20krz
c20krzon
c20krzoff
c2kr4wz
c2kr4wzon
c2kr4wzoff
c2krz
c2krzon
c2krzoff
c200r4wz
c200r4wzon
c200r4wzoff
c200rz
RMS gain for 2V, 200V, and 750V ranges
RMS offset for 2V, 200V, and 750V AC ranges
RMS gain for 200mV and 20V AC ranges
RMS offset for 200mV and 20V AC ranges
Average gain for 2V, 200V, and 750V AC ranges
Average offset for 2V, 200V, and 750V AC ranges
Average gain for 200mV and 20V AC ranges
Average offset for 200mV and 20V AC ranges
100:1 divider attenuation factor
500:1 divider attenuation factor
Positive peak offset for 200mV AC range
Negative peak offset for 200mV AC range
Positive and negative peak offset for 2V, 200V, and 750V AC ranges
Positive peak offset for 20V AC range
Negative peak offset for 20V AC range
Self-calibration code for frequency compensation DAC, 100:1 divider
Self-calibration code for frequency compensation DAC, 500:1 divider
200µA zero
2mA zero
20mA zero
200mA zero
2A zero
x50 divider zero
1000V zero
200V zero
20V zero
10V zero
2V zero
200mV zero
1MΩ 4-wire zero
1MΩ 2-wire zero
200kΩ 4-wire zero
200kΩ 2-wire zero
20kΩ 4-wire zero
20kΩ 4-wire zero OC on
20kΩ 4-wire zero OC off
20kΩ 2-wire zero
20kΩ 2-wire zero OC on
20kΩ 2-wire zero OC off
2kΩ 4-wire zero
2kΩ 4-wire zero OC on
2kΩ 4-wire zero OC off
2kΩ 2-wire zero
2kΩ 2-wire zero OC on
2kΩ 2-wire zero OC off
200Ω 4-wire zero
200Ω 4-wire zero OC on
200Ω 4-wire zero OC off
200Ω 2-wire zero

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
