Keithley 2002 Calibration Manual

Performance Verification
1-3
Table 1-1
Recommended Test Equipment for Performance Verification
Mfg. Model Description Specifications*
Fluke 5700A Calibrator ±5ppm basic uncertainty.
DC Voltage:
190mV: ±11ppm
1.9V: ±7ppm
19V: ±5ppm
190V: ±7ppm
1000V: ±9ppm
AC Voltage, 10Hz-1MHz
(40Hz-20kHz specifications):
190mV: ±150ppm
1.9V: ±78ppm
19V: ±78ppm
190V: ±85ppm
750V: ±85ppm (50Hz-1kHz)
DC current:
190µA: ±103ppm
1.9mA: ±55ppm
19mA: ±55ppm
190mA: ±65ppm
1.9A: ±96ppm
AC Current, 40Hz-10kHz
(40Hz-1kHz specifications):
190µA: ±245ppm
1.9mA: ±160ppm
19mA: ±160ppm
190mA: ±170ppm
1.9A: ±670ppm
Resistance:
19 Ω : ±26ppm
190 Ω : ±17ppm
1.9k Ω : ±12ppm
19k Ω : ±11ppm
190k Ω : ±13ppm
1.9M Ω : ±19ppm
19M Ω : ±47ppm
100M Ω : ±120ppm
Fluke 5725A Amplifier AC Voltage, 1kHz-10kHz:
750V: ±85ppm
Fluke 5700A-03 Wideband AC option 190mV ± 0.22%, 1.9V ± 0.3% @ 2MHz
Fluke 5440A-7002 Low-thermal cable set
Keithley CA-18-1 Low-capacitance cable Low-capacitance dual banana to dual banana shielded cable (for
ACV), 1.2m (4 ft.) in length.
Keithley R-289-1G 1G Ω resistor NOTE: Resistor should be characterized to within ±1,000ppm and
mounted in shielded test box (see procedure).
Metal component box (for 1G Ω
resistor)
Banana plugs (2) for test box One insulated, one non-insulated.
Keithley 3940 Multifunction Synthesizer 1Hz-15MHz, ±5ppm
General
Radio
1433-T Precision Decade Resistance Box 10-400 Ω , ±0.02%
— — Megaohmmeter 1G Ω , ±0.5%
* 90-day calibrator specifications shown include total absolute uncertainty at specified output.

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
