Keithley 2002 Calibration Manual

A-2 Specifications
Specifications
The following pages contain the complete specifications for the 2002.
Every effort has been made to make these specifications complete by charac-
terizing its performance under the variety of conditions often encountered in
production, engineering, and research.
The 2002 provides Transfer, 24-hour, 90-day, 1-year, and 2-year specifica-
tions, with full specifications for the 90-day, 1-year, and 2-year intervals. This
allows the operator to utilize 90-day, 1-year, or 2-year recommended calibra-
tion intervals, depending upon the level of accuracy desired. As a general rule,
the 2002’s 2-year performance exceeds a 6½-digit DMM’s 90-day, 180-day, or
1-year specifications.
Absolute Accuracy
All DC specifications are given as relative accuracies. To obtain absolute
accuracies, the absolute uncertainties of the calibration sources must be
added to the relative accuracies. The absolute uncertainties for the calibration
sources used during Keithley’s factory calibration are included in the specifi-
cations. The uncertainties of the operator’s sources may be different.
All AC specifications are given as absolute accuracies.
Typical Accuracies
Accuracy can be specified as typical or warranted. All specifications
shown are warranted unless specifically noted. Almost 99% of the 2002’s
specifications are warranted specifications. In some cases it is not possible to
obtain sources to maintain traceability on the performance of every unit in
production on some measurement (e.g., high-voltage, high frequency signal
sources with sufficient accuracy do not exist). These values are listed as
typical.
2002 Specified Calibration Intervals
Measurement 24 90 1 2
Function Hour
1
Day
2
Year
2
Year
2
DC Volts • • • •
DC Volts Peak Spikes • • •
AC Volts rms •
3
•
3
•
3
AC Volts Peak • • •
AC Volts Average •
3
•
3
•
3
AC Volts Crest Factor • • •
Ohms • • • •
DC Current • • • •
DC In-Circuit Current • • •
AC Current • • •
Frequency • • •
Temperature (Thermocouple) • • •
Temperature (RTD) • • • •
1
For T
CAL
±1°C.
2
For T
CAL
±5°C.
3
For ±2°C of last AC self-cal.

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
