Keithley 2601B Reference Manual

Series 2600B
System SourceMeter® Instrument Reference Manual Section 7:
TSP command reference
2600BS-901-01 Rev. B / May 2013 7-277
Usage
operationRegister = status.operation.instrument.digio.trigger_overrun.condition
operationRegister = status.operation.instrument.digio.trigger_overrun.enable
operationRegister = status.operation.instrument.digio.trigger_overrun.event
operationRegister = status.operation.instrument.digio.trigger_overrun.ntr
operationRegister = status.operation.instrument.digio.trigger_overrun.ptr
status.operation.instrument.digio.trigger_overrun.enable = operationRegister
status.operation.instrument.digio.trigger_overrun.ntr = operationRegister
status.operation.instrument.digio.trigger_overrun.ptr = operationRegister
operationRegister
The status of the operation status digio I/O overrun register; a zero (0) indicates no
bits set (also send 0 to clear all bits); other values indicate various bit settings
Details
These attributes are used to read or write to the operation status digital I/O overrun registers. Reading a status
register returns a value. The binary equivalent of the returned value indicates which register bits are set. The
least significant bit of the binary number is bit B0, and the most significant bit is bit B15. For example, if a value
of 1.02600e+03 (which is 1026) is read as the value of the condition register, the binary equivalent is
0000 0100 0000 0010. This value indicates that bit B1 and bit B10 are set.
B15
B14
B13
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B0
**
>
>
>
>
>
>
>
>
>
>
>
>
>
>
*
0
0
0
0
0
1
0
0
0
0
0
0
0
0
1
0
* Least significant bit
** Most significant bit
A set bit indicates that the specified digital I/O line generated an action overrun when it was triggered to generate
an output trigger.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set contents (on
page E-1) and Enable and transition registers (on page E-19). The individual bits of this register are defined in
the following table.
Bit Value Description
B0
Not used
Not applicable
B1
status.operation.instrument.digio.trigger_overrun.LINE1
Bit B1 decimal value: 2
B2
status.operation.instrument.digio.trigger_overrun.LINE2
Bit B2 decimal value: 4
B3
status.operation.instrument.digio.trigger_overrun.LINE3
Bit B3 decimal value: 8
B4
status.operation.instrument.digio.trigger_overrun.LINE4
Bit B4 decimal value: 16
B5
status.operation.instrument.digio.trigger_overrun.LINE5
Bit B5 decimal value: 32
B6
status.operation.instrument.digio.trigger_overrun.LINE6
Bit B6 decimal value: 64
B7
status.operation.instrument.digio.trigger_overrun.LINE7
Bit B7 decimal value: 128
B8
status.operation.instrument.digio.trigger_overrun.LINE8
Bit B8 decimal value: 256
B9
status.operation.instrument.digio.trigger_overrun.LINE9
Bit B9 decimal value: 512
B10
status.operation.instrument.digio.trigger_overrun.LINE10
Bit B10 decimal value: 1,024
B11
status.operation.instrument.digio.trigger_overrun.LINE11
Bit B11 decimal value: 2,048
B12
status.operation.instrument.digio.trigger_overrun.LINE12
Bit B12 decimal value: 4,096
B13
status.operation.instrument.digio.trigger_overrun.LINE13
Bit B13 decimal value: 8,192
B14
status.operation.instrument.digio.trigger_overrun.LINE14
Bit B14 decimal value: 16,384
B15
Not used
Not applicable
