Keithley 2651A User Manual

Model 2651A High Power System SourceMeter® Instrument User's Manual Section 1: Introduction
2651A-900-01 Rev. A / March 2011 1-3
• Characterization of power discretes (on page 6-1): Demonstrates how to use the Keithley
Instruments Model 2651A with a second Series 2600A System SourceMeter
®
instrument to
characterize power MOSFETs and IGBTs. This example introduces the interaction between two
instruments' trigger models. The application performs pulsed measurements, collecting IV curve
data and placing it in a Microsoft
®
Excel
®
compatible file format for graphic and analysis.
• Increasing SMU current sourcing ability (on page 7-1): Demonstrates how to combine two
Keithley Instruments Model 2651A instruments with an additional Series 2600A System
SourceMeter
®
instrument, and characterizes the resistance of a power MOSFET by sweeping
current up to 100 A.

Keithley 2651A Specifications

General

Brand	Keithley
Model	2651A
Category	Measuring Instruments
Language	English
