Model 2651A High Power System SourceMeter® Instrument User's Manual Section 4: Making basic front-panel measurements
2651A-900-01 Rev. A / March 2011 4-3
Step 5: Observe readings on the display
1. Observe the readings on the display. Press the TRIG key if necessary to trigger the instrument to
begin taking readings. The readings are on the top line, and source and limit values are on the
bottom line. For the 10 kΩ resistor, typical display values are:
1.00000mA
SrcA: +10.0000 V LimA:010.0000mA
2. Press the MEAS key several times to display measured voltage, resistance, power, and current.
Typical values for the 10 kΩ resistor are:
10.0000 V, 10.0000 kΩ, 10.0000 mW, and 1.00000 mA
Step 6: Turn output off
When finished, turn the output off by pressing the OUTPUT ON/OFF control. The OUTPUT indicator
light will turn off.
