Section 3: Using the web interface Model 2651A High Power System SourceMeter® Instrument User's Manual
Figure 7: Downloading the reading buffer
1
3
2
5. Notice that the Source Value column is not populated. To collect source values, before taking
readings, use TSB Embedded to set the following attribute:
smua.nvbuffer1.collectsourcevalues = 1.
Figure 8: Sample downloaded reading buffer
TSP Express
The TSP
®
Express tab provides access to the TSP Express Launch page. From this page, click the
Launch button to start TSP Express.
3-8 2651A-900-01 Rev. A / March 2011
