Model 2651A High Power System SourceMeter® Instrument User's Manual Section 3: Using the web interface
NOTE
Only one TSB Embedded or TSP Express session can be running and connected to the same
instrument.
Figure 9: Select TSP Express
To run TSP Express:
1. From the navigation area on the left side of the web interface, select TSP Express. The TSP
Express page is displayed.
2. Click the Launch button. The TSP Express window opens.
3. There is a help pane on the right side of the main window. You can adjust the width of the help
pane by sliding the vertical bar. Click and follow the step-by-step example to become familiar with
TSP Express (there is a link to the example in the TSP Express Introduction's first paragraph).
2651A-900-01 Rev. A / March 2011 3-9
