Section 3: Using the web interface Model 2651A High Power System SourceMeter® Instrument User's Manual
Exercise: Create and run a script with TSB Embedded
The following programming example illustrates the setup and command sequence of a basic
source-measure procedure with the following parameters:
• Source function and range: Volts, autorange
• Source output level: 5 V
• Current compliance limit: 10 mA
• Measure function and range: Current, 10 mA
To create and run a sample script with TSB Embedded:
1. From the navigation on the left side of the web interface, select TSB Embedded. The TSB
Embedded page is displayed.
Figure 4: Select TSB Embedded
2. To create the example script, enter the name of the TSP script: basic_source_measure at the
location shown by (1) in the following illustration.
3-4 2651A-900-01 Rev. A / March 2011
