Keithley DMM6500 User Manual

Section
2: Performance verification DMM6500 6½-Digit Multimeter with Scanning
Calibration and Adjustment Manual
2-4 DMM6500-905-01 Rev. E June 2021
Calibration verification limits
The calibration verification limits stated in this section have been calculated using only the DMM6500
one-year accuracy specifications and ambient temperature ±5 °C from T
CAL
(the temperature at which
the instrument was calibrated). They do not include test equipment uncertainty. If a particular
measurement falls outside the allowable range, recalculate new limits based on both the DMM6500
specifications and corresponding test equipment specifications.
Specifications and characteristics are subject to change without notice; please refer to the
Keithley
Instruments website (tek.com/keithley) for the most recent specifications.
Example reading limit calculation
Assume you are testing the 10 V dc range using a 10 V input value. Using the DMM6500 one-year
accuracy specification for 10 V dc of ± (25 ppm of reading + 5 ppm of range), the calculated limits are:
Reading limits = 10 V ± [(10 V × 25 ppm) + (10 V × 5 ppm)]
Reading limits = 10 V ± (0.00025 + 0.00005) V
Reading limits = 10 V ± 0.00030 V
Reading limits = 9.99970 V to 10.00030 V
Calculating resistance reading limits
Resistance reading limits must be recalculated based on the actual calibration resistance values
supplied by the equipment manufacturer. Calculations are performed in the same manner as shown
in the preceding example. Use the actual calibration resistance values instead of the nominal values
in the example when performing your calculations.
For example, assume that you are testing the 10 kΩ range using an actual 10.03 kΩ calibration
resistance value. Using DMM6500 one-year 10 kΩ range accuracy of ± (75 ppm of reading + 6 ppm
of range), the calculated reading limits are:
Reading limits = 10.03 kΩ ± [(10.03 kΩ x 75 ppm) + (10 kΩ x 6 ppm)]
Reading limits = 10.03 kΩ ± [(0.7523) + (0.06)] Ω
Reading limits = 10.03 kΩ ± 0.8123 Ω
Reading limits = 10.029188 kΩ to 10.030812 kΩ

Keithley DMM6500 Specifications

General

Resolution	6.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
AC Current Range	10 µA to 10 A
Temperature Range	-200 °C to 1820 °C
Display	5-inch capacitive touch screen
Resistance Range	100 MΩ
Frequency Range	3 Hz
Sampling Rate	1 MS/s
Connectivity	USB, LAN, GPIB (optional), TSP-Link
Memory	7 million readings
