Promig 530
Working voltag
(safety voltage)
50 VDC
Max. load
(nominal values)
100 W
Kuormitettavuus (nimellisarvot)
60 % ED 520 A
100 % ED 440 A
Operation principle 4 roll feed
Diameter of feed roll 32 mm
Wire feed speed I
0...18 m/min
Wire feed speed II ¹)
0...25 m/min
Filler wires ø Fe, Ss 0,6...2,4
ø Cored wire 0,8...2,4
ø Al 1,0...2,4
Wire reel
max. weight 20 kg
max. size ø 300 mm
Gun connector Euro
Operation temperature range -20...+40 °C
Storage temperature range -40...+60 °C
Degree of protection IP 23 C
Dimensions without handles length 640 mm
width 230 mm
height 430 mm
Weight
21 kg
¹) Changes of speed are carried out by changing gear wheel and jumber block selection on
circuit card A001.
Control panels
MC 6263501 ML 6263502
Adjustment for welding current,
voltage and wire feed speed
Potentiometers Potentiometers
Welding current, voltage and wire feed
speed displays
LED displays LED displays
Measuring recording to memory, recall
of welding parameters (WPS)
yes yes
MIG/MMA dynamics control
Potentiometer Potentiometer
Selecto memory channels 5 pc
Synergic MIG
- 9 programs
Synergic PULSED MIG
- 9 programs
The products meet conformity requirements for CE marking.
9. TECHNICAL DATA
