Promig 530 / 0612 – 9© kemPPi oy
21 6
4
5
7
3
62 6
4
5
7
3
1 4
2
3
5
SYNERGIC MIG welding
1. Select with selecting switch for method MIG
two-sequence procedure or MIG four-sequence
procedure
2. Select with SYNERGIC mode switch the position
1-MIG
3. Set selecting switches for material and diameter
corresponding to ller wire used by you
4. Select the control mode: local control, remote control
or gun control
5. Adjust the required power with the potentiometer
and the arc length with the potentiometer. Values are
shown in displays
6. Set welding dynamics on zero or required position
7. Weld and adjust welding power and arc length when
needed.
SYNERGIC PULSED MIG welding
1. Select with selecting switch for method MIG two-sequence procedure or MIG four-sequence
procedure
2. Select with SYNERGIC mode switch the position
3. Set selecting switches for material and diameter
corresponding to ller wire used by you
4. Select the control mode: local control, remote control
or gun control
5. Adjust the required power with the -potentiometer
and the arc lenth with the potentiometer. Values are
shown in displays
6. Set welding dynamics on zero or required position
7. Weld and adjust welding power and arc length when
needed.
MMA welding
1. Select MMA welding with selecting switch for method
2. Select the control mode: local control, remote control or gun control
3. Adjust required MMA current. Values are shown in displays
4. Set welding dynamics on position zero or on required position
5. Weld and adjust MMA current when needed
