Promig 530 / 0612 – 7© kemPPi oy
21 5
3
4
6
21 5
3
4
5 4
3
4
12 6
1.2.3. Quick guide for operation of MC panel
MIG welding with independent adjustments for wire feed and voltage
1. Select with selecting switch for method MIG two sequence procedure or MIG four-sequence
procedure
2. Select with SELECTO mode switch the position OFF
3. Select the control mode: local control, remote control or gun control
4. Adjust required set values for wire feed speed and voltage. Values are shown in displays
5. Set welding dynamics at zero position or at required position
6. Weld and adjust wire feed speed and voltage when needed
MIG welding with welding values stored in SELECTO memories
1. Select with selecting switch for method MIG two-sequence procedure or MIG four-
sequenceprocedure
2. Select with SELECTO mode switch the position ON
3. Select the channel selection mode: local control, remote control or gun control
4. Select required channel 1...5. Welding values stored on channel are shown in displays
5. Weld and select another channel when needed. You can change the channel also during
welding
Programming of SELECTO memories
1. Select required channel 1...5
2. Select with SELECTO mode switch the position
SET
3. Select the control mode: local control, remote control
or gun control
4. Search by welding correct values for wire feed speed,
voltage and welding dynamics
