02/26/02
Page 7.1
print mechanism
Kent Pad Printer Canada Inc.
During the flat print cycle machine undergoes various stages of movement:
1. Squeegee comes down / object comes up.
2. Squeegee moves across the screen for printing.
3. Flooder comes down / object comes down.
4. Flooder moves across the screen for inking.
Flat print mechanism
