KENT SP500 - Round Print Mechanism

02/26/02
Page 7.2
print mechanism
Kent Pad Printer Canada Inc.
During the round print cycle machine undergoes various stages of movement:
1. Squeegee comes down / object comes up.
2. Screen moves across for printing.
3. Flooder comes down / object comes down.
Round print mechanism
