CA3 Z3 DEVICE ALARM MUST BE PRESENT FOR 30
SECONDS
E00 PANEL CAN BE RESET IMMEDIATELY DISCHARGE
OUTPUT HAS OPERATED
To allow reset of the panel to be prohibited before the
extinguishant discharge has fully completed.
E01
TO
E29
PANEL CAN BE RESET 1 MINUTE TO 29 MINUTES
AFTER DISCHARGE OUTPUT HAS OPERATED
E30 PANEL CAN BE RESET 30 MINUTES AFTER
DISCHARGE OUTPUT HAS OPERATED
-00 NO EXTINGUISHANT DELAY Time delay between activation and extinguishant release
output operating.
This menu is accessed using the lamp test (+100)
button. The time is adjusted using the Mode button for
10’s and the Select button for 5’s.
Once the time is selected the Enter button is used to
store the value.
-05 5 SECONDS EXTINGUISHANT DELAY
-10
TO
-55
INCREMENT EXTINGUISHANT DELAY IN FIVE
SECOND STEPS
-60 60 SECONDS EXTINGUISHANT DELAY
060 EXTINGUISHANT DURATION TIME IN SECONDS Time that extinguishant release output is activated.
Note: Panel can not be reset until this time has expired
except by operating the terminate extinguishant switch
located under the front cover.
This menu is accessed using the lamp test (+100)
button. The time is adjusted using the Mode button for
10’s and the Select button for 5’s.
Once the time is selected the Enter button is used to
store the value.
060
TO
295
INCREMENT EXTINGUISHANT DURATION IN FIVE
SECOND STEPS
300 EXTINGUISHANT DURATION TIME IN SECONDS
NOTE: Setting the option C15 and those marked with asterisks does not comply with EN12094-1
Once the required configuration options have been set, the Access level 3 switch must be
returned to its normal position. The General fault indicator will remain lit if the Access level 3
switch is not turned off.
