13 Using as counting system
13.1 Connecting the bulk scales to the reference balance EWJ via the optional
interface cable CCA-A01
TCCA-A01-A interface cable:
1 (connectors with a thin conductor)
• Connector for RS-232 interface of EWJ scale
• Printer connector
2
(connector with a thick conductor)
• Connector for IFS scale
TCCA-A02-B interface cable:
1
(connectors with a thin conductor)
• Connector for RS-232 interface of EWJ scale
• Connector for CFS-A03 signal light
2
(connector with a thick conductor)
• Connector for IFS scale
It is possible to use the signal light and the printer at the same time.
