User Manual
SUPM1
page 72 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
User Interface Reference
Table 39: AP: / unit-x, Configuration - Unit Parameters - Provisioning Set 1
Operation Name Parameter Name Range Description / Details
Provisioning Set 1 Mode Of Operation V5
V5 is the KEYMILE proprietary V5CAS signalling
mode of operation between the SUPM1 unit and
the VOIP1 unit.
Mercury CAS is the signalling mode of operation
(used in the United Kingdom) between the
SUPM1 unit and the P12 transport units in the
application with a Mercury CAS enabled switch.
Please refer to section 5.2 Mercury CAS Modes
of Operation (on page 36) for a description of the
MCAS signalling modes.
Mercury CAS Direct Line
Mercury CAS Loop Calling
PBX
Mercury CAS Earth Calling
PBX
Mercury CAS PBX Exten-
sion
Phone-Exchange
Phone-Exchange interworks with the analogue
exchange side line card TUXA1 or any 3rd party
equipment.
Please refer to section 5.3 Phone-Exchange
Mode of Operation (on page 39) for a description
of this signalling mode.
Phone-Phone Auto Ring
Down
Phone-Phone modes are used in EOW applica-
tions without the need of an exchange.
Two subscribers have to be cross connected
directly.
Please refer to section 5.4 Phone-Phone Mode
of Operation (on page 41) for a description of
this signalling mode.
To Next Page
