User Interface Reference
Blocked Port Line
Feed Enabled
If set to true, the analogue a/b-wires on the user
ports are still fed with DC-current during port
blocking.
Note: This parameter is controlled by the “mode
of operation” parameter. Please refer to Table
38.
Metering Pulse
Enabled
If set to true, the metering pulse function towards
the subscriber is enabled.
Note: This parameter is controlled by the “mode
of operation” parameter. Please refer to Table
38.
Pulse On Answer
Enabled
If set to true, a metering pulse can be sent to the
subscriber when the called subscriber goes off-
hook.
Note: This parameter is controlled by the “mode
of operation” parameter. Please refer to Table
38.
Polarity Reversal
Enabled
If set to true, a polarity reversal can be applied to
the subscriber line.
Note: This parameter is controlled by the “mode
of operation” parameter. Please refer to Table
38.
Phone-Phone Sig-
nalling
On-Hook 4 characters
On-hook CAS pattern “abcd” which is used by
the local and remote subscribers.
Valid characters are “0” and “1”.
The default CAS pattern is “1101”.
Off-Hook 4 characters
Off-hook CAS pattern “abcd” which is used by
the local and remote subscribers.
Valid characters are “0” and “1”.
The default CAS pattern is “0101”.
Phone-Exchange
Signalling
Towards Exchange,
On-Hook
4 characters
On-hook CAS pattern “abcd” which is sent
towards the exchange.
Valid characters are “0” and “1”.
The default CAS pattern is “0101”.
Towards Exchange,
Off-Hook
4 characters
Off-hook CAS pattern “abcd” which is sent
towards the exchange.
Valid characters are “0” and “1”.
The default CAS pattern is “0001”.
Towards Exchange,
Ground Key
4 characters
Ground key CAS pattern “abcd” which is sent
towards the exchange.
Valid characters are “0” and “1”.
The default CAS pattern is “1001”.
From Exchange,
Ringing
4 characters
Ringing CAS pattern “abcd” which is received
from the exchange.
Valid characters are “0”, “1” and “x”. “x” means
“don’t care”.
The default CAS pattern is “x101”.
Note that polarity reversal during ringing is not
supported.
Table 39: AP: / unit-x, Configuration - Unit Parameters - Provisioning Set 1 (continued)
Operation Name Parameter Name Range Description / Details
