User Manual
SUPM1
page 74 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
User Interface Reference
8.2.3.3 AP: / unit-x, Configuration - Unit Parameters - Provisioning Set 2
The provisioning set 2 parameters are identical to the provisioning set 1
parameters:
Please refer to section 8.2.3.2 AP: / unit-x, Configuration - Unit Parameters -
Provisioning Set 1 (on page 71).
8.2.3.4 AP: / unit-x, Configuration - Advanced Unit Parameters
From Exchange,
Metering Pulse
4 characters
Metering pulse CAS pattern “abcd” which is
received from the exchange.
Valid characters are “0”, “1” and “x”. “x” means
“don’t care”.
The default CAS pattern is “x011”.
Note that polarity reversal during metering pulse
is not supported.
From Exchange,
Polarity Reversal
4 characters
Polarity reversal CAS pattern “abcd” which is
received from the exchange.
Valid characters are “0”, “1” and “x”. “x” means
“don’t care”.
The default CAS pattern is “0001”.
Table 39: AP: / unit-x, Configuration - Unit Parameters - Provisioning Set 1 (continued)
Operation Name Parameter Name Range Description / Details
Table 40: AP: / unit-x, Configuration - Advanced Unit Parameters
Operation Name Parameter Name Range Description / Details
Advanced Unit
Parameters, Trans-
mission Path
CAS AIS Debounc-
ing Time
0.1 … 1.0 … 25.5 s,
step 0.1 s
This is the time the SUPM1 uses to accept an
AIS on voice and signalling (without interrupting
an ongoing call).
This setting can be important if you have a pro-
tected transmission path. During switchover from
the working to the protecting path the arriving
PCM signal on SUPM1 carries AIS.
If you loose the voice path during a transmission
protection switchover, then increase the value of
this parameter.
