User Interface Reference
8.2.3.5 AP: / unit-x, Configuration - Line Test Parameters
Advanced Unit
Parameters, Meter-
ing Pulse After On
Hook
Time-Out 0.0 … 4.0 … 25.5 s,
step 0.1 s
This timer defines the time a SUPM1 user port
may send out a metering pulse after the sub-
scriber went on-hook. Also the voice path
remains transparent during this time.
Recommended range: 1 … 5 s.
Advanced Unit
Parameters, Pulsed
No Battery
Pulsed No Battery
Wire Selection
a-b-Wires Disconnected
Physical behaviour of a pulsed no battery infor-
mation element.
Note: This signalling parameter is for the V5CAS
mode of operation available only.
a-Wire Disconnected
Advanced Unit
Parameters, Power
Management
Enable Current
Reduction
If set to true, the loop current of active subscriber
ports is managed to avoid an overload of the
loop current power supply.
Refer to section 5.13 Power Management (on
page 59).
Reduced Loop Cur-
rent
15 mA
The reduced loop current is assigned to new
calls in the power state 1.
Refer to section 5.13 Power Management (on
page 59).
19.5 mA
23.5 mA
Table 40: AP: / unit-x, Configuration - Advanced Unit Parameters (continued)
Operation Name Parameter Name Range Description / Details
Table 41: AP: / unit-x, Configuration - Line Test Parameters
Operation Name Parameter Name Range Description / Details
Line Test Parame-
ters
Enable Cyclic Line
Test
This enables the cyclic line test for all enabled
user ports of the unit.
Line Test Schedule Daily
Select the appropriate test interval.
Weekly
Start Date And
Time
<DD> <MM> <YYYY>
<hh> <mm> <ss>
Select the appropriate line-test start date and
time.
Default date: Actual date plus 1 day.
Default time: 02:00:00
Foreign Voltage
If set to true, the foreign voltage line-tests will be
done.
Noise
If set to true, the noise line-tests will be done.
