Keyprocessor Orion User Manual

12
5.3.1 Cabling requirement
The required cable between the Orion and the Network controller is displayed below:
Cable
Communication type
Distance
Communication between
UTP/STP Cat ≥3
RS422
1200m
Netwerk controller and Orion
5.3.2 Card reader and IO connections
When exchanging a reader Orbit for an Orion Smart door controller the following table may be
used:
Orbit 2
Reader 1
Connection
description
Orion
Reader & IO-1
iProtect™ default
+5V 200mA MAX
Reader power
+V
GND
GND (digital ground)
C
D1 / CLK
D1 / Clock
D1
D0 / DAT
D0 / Data
D0
LED
LED
LD
⏚
Earth ground
⏚
Inputs 1
Inputs 1
Input/Output
IN0
Digital input
A1
Loop
COM 0+1
GND (digital ground)
C
C
IN1
Digital input
A2
Push button
IN2
Digital input
A3
Door status
COM 2+3
GND (digital ground)
C
IN3
Digital input
T1
Door in latch mode
Outputs 1
Outputs 1
0
Digital output
H1
Door control
GND
GND (digital ground)
C
1
Digital output
O2
Alarm
Orbit 2
Reader 2
Connection
description
Orion
Reader & IO-2
iProtect™ default
+5V 200mA MAX
Reader power
+V
GND
GND (digital ground)
C
D1 / CLK
D1 / Clock
D1
D0 / DAT
D0 / Data
D0
LED
LED
LD
⏚
Earth ground
⏚
Inputs 2
Inputs 2
Input/Output
IN0
Digital input
A4
Loop
COM 0+1
GND (digital ground)
C
C
IN1
Digital input
A5
Push button
IN2
Digital input
A6
Door status
COM 2+3
GND (digital ground)
C
IN3
Digital input
T2
Door in latch mode
Outputs 2
Outputs 2
0
Door Output
H2
Door control
GND
GND (digital ground)
C
1
Alarm output
O5
Alarm
