8 Technical specifications
Housing
Measurements:
110,0 x 47,0 x 93,0 mm (L x W x H)
Weight:
0,25 Kg
Mounting
Dinrail
35 mm (NEN-EN 50022)
Communication
PRT1
RJ45 socket, RS422
Pin out
Pin 1 = RXB Pin 5 = GND
Pin 2 = RXA Pin 6 = TXB
Pin 3 = TXB Pin 7,8 = GND
Pin 4 = 12V dc
PRT2
RJ45 socket, RS485
Pin out
Pin 1 = RXB Pin 5 = GND
Pin 2 = RXA Pin 6 = RXA
Pin 3 = RXB Pin 7,8 = GND
Pin 4 = 12V dc
Card reader
Reader power (+V)
Voltage
12.0V DC
Current
500mA (one Polyfuse for both readers)
Interface
Clock/Data
depending of used cable and card reader
Wiegand
depending of used cable and card reader
Power supply & consumption
Voltage (+)
12,0 – 24V DC
Power
Average
0,48W (no load)
Digital I/O
Digital output (O1, O2, O3, O4, O5, O6)
max. Voltage 28V; Open collector output; sinked
current. Max. current 300mA (Polyfuse)
High power output (H1, H2)
Current limiting, switching to GND, max. 2.5A
Digital input (T1, T2)
Switching to GND, <20K ohm
Digital input (D0/D1) Reader IO-1
Switching to GND, <20K ohm
Digital input (D0/D1) Reader IO-2
Switching to GND, <20K ohm
Environment inputs
ADC input (A1, A2, A3, A4, A5, A6)
value
0-60K ohm. Response time <250ms
Switching to GND, <2K ohm. Response
time 20ms
Environment sensor
kpSensor
Sensor
kpSensor
2
Type
Temperature/Humidity
Indicators
Visual
RGB-LED
Sound
Multi-tone buzzer
microSD
microSD
Type: SDHC, up to 32GB
End of line jumper
End Of Line resistor
120 ohm
