Keyprocessor Orion User Manual

8
L
4.1.1 Labels
In this chapter, the labels of the Orion will be described, whereby ADC stands for Analog /
Digital Converter:
Reader & IO-1
B
Description
C
Description
C
GND (digital ground)
A1
ADC input 1
T1
Digital input (card reader tamper)
A2
ADC input 2
LD
LED control card reader
A3
ADC input 3
D0
DO/Data or Digital input
C
GND (digital ground)
D1
D1/Clock or Digital input
H1
High Power output 1
O1
Digital output 1
C
GND (digital ground)
C
GND (digital ground)
O2
Digital output 2
+V
Power connection card reader
O3
Digital output 3
D
Description
⏚
Earth ground
-
GND (digital ground)
+
Power connection Orion (12-24V DC)
T
Tamper input Orion
I
Description
A
A-RS485
B
B-RS485
C
GND (digital ground), only for use of communication or the sensor!
S
kpSensor
K
L
J
I
D
B
A
C
