Keyprocessor Orion User Manual

4
2 Uses
Depending on the situation, the Orion can be used in many different ways. The Orion can be
applied if:
- the existing reader Orbit must be replaced/exchanged or
- multiple Orion’s are needed, communicating over one data line or
- more functionality is needed.
2.1 Functions and support
Depending on the use of the Orion, more or less functionality is available. The table below
shows the features:
Overview > Orion as Orbit replacement unit:
Amount
Connection
Orions (per port)
1
Controller type: iPU-8 (Max. 8
Orions) or Polyx (Max. 2 Orions)
Digital inputs
8
A1, A2, A3, A4, A5 A6, T1, T2
Digital outputs
4
H1, H2, O2, O5
Card reader Wiegand/ABA
2
LD, D0, D1, C en V+
LED status
Yes
Communication
PRT1 - RS422
Internal temperature measurement
Yes
Power supply measurement
Yes
Reader power measurement
Yes
Current: card readers
Yes
Overcharge / Short circuit H1 H2
Yes
Softstarting outputs
Yes
Overview > Orion in a communication bus:
Amount
Connection
Orions (per bus)
8
Controller type: Polyx (Max. 16
Orions per Polyx)
Digital inputs
2
T1, T2
Digital outputs
8
O1, O2, O3, O4, O5, O6, H1 en
H2
Monitort inputs (ADC)
6
A1, A2, A3, A4, A5, A6
Orion tamper input
1
T
Card reader Wiegand/ABA
2*
LD, D0, D1, C en V+
kpSensor
2**
C, S
Location buzzer
Ja
LED status
Ja
Audio
Future use
microSD card
Future use
Communication type
PRT 2 - RS485
Internal temperature measurement
Yes
Power supply measurement
Yes
Reader power measurement
Yes
Current: card readers
Yes
Overcharge / Short circuit H1 H2
Yes
Softstarting outputs
Yes
