18 Keysight E5061B Network Analyzer
Installation
Environmental Requirements
1-
Figure 1-1 Ventilation space at the installation
Protection Against Electrostatic Discharge (ESD)
Set up a static-safe work-station to protect the electronic components from
the damage by the electrostatic discharge (ESD) as shown in Figure 1-2.
Figure 1-2 Example of the static-safe work station
Place the E5061B in a proper position as shown in Figure 1-1
