24 Keysight E5061B Network Analyzer
Installation
Power Supply
1-
Power Supply
Before turning on the E5061B power, check the following.
Verification of the Power Supply
Confirm that the power supplied to the E5061B meets the following
requirements:
Verification and Connection of Power Cable
The three-wire power cable attached to the E5061B has one wire serving as a
ground. Using this power cable allows the E5061B to be grounded, thereby
protecting you against electrical shock from the power outlet.
Step 1. Confirm that the power cable is not damaged.
Step 1. Use the supplied cable to connect between the power cable receptacle
(Figure 1-5 on page 27) on the rear panel of the E5061B and a three-wire
power outlet with the grounding prong firmly connected in the ground slot
Power cord list, 16000-99101 shows the power cable options.
Blown Fuses
If the fuse appears to have blown during operation, this instrument may be
subject to failure and must be repaired. For any assistance, contact Keysight
Technologies Customer contact center listed at the end of this guide.
The product uses the following fuse types:
UL/CSA Type, Slow-Blo, 10 A-250 Vac.
Requirements
Voltage
90 to 132 VAC or 198 to 264 VAC
1
1. Switched automatically by the E5061B in conformity to the voltage used.
Frequency 47 to 63 Hz
Maximum power consumption 300 VA
NEVER use a power cable showing any sign of damage. Faulty cables can
cause electrical shock.
Use the supplied power cable with grounding wire to securely ground the
E5061B.
