Installation
Starting the E5061B
1-
Starting the E5061B
This section describes how to turn on/off the E5061B power and how to cut off
the power supply in an emergency.
Turning the Power ON and OFF
The standby switch can turn/off the E5061B. The color on the button shows
the status, as shown below:
Perform the following steps to turn the power ON or OFF.
Turning the Power ON
Step 1. Confirm if the Line Switch on the rear panel is on. The switch should always
be turned on.
Step 2. Press the standby switch once and it changes to green color.
This operation turns ON the power, and the E5061B starts the self-test.
Step 3. Confirm that the self-test indicates normal operation.
Normal operation is confirmed by the self-test if no error message appears.
Turning the Power OFF
Step 1. To turn off the power of the E5061B, first, press this standby switch or send a
shutdown command from the external controller to activate the shutdown
process (the process of software and hardware necessary to turn off the
power supply). This puts the E5061B into the standby state and the button
changes to orange color.
Indicator Color Description
Green Normal power on status
Orange Standby status
Red Illegal power on status
