Reference 22

Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide 337

Segmented

Memory

Acquisition on One

Analog Channel

The following picture shows a binary file of a segmented memory acquisition on

one analog channel.

File Header

12 bytes

Waveform Header 2

140 bytes

Waveform Data

Header 1

12 bytes

Pod 1 Timing Data

buffer size

Waveform Data

Header 2

12 bytes

Pod 2 Timing Data

buffer size

Number of Waveforms = 2

Number of Waveform Buffers = 1

Buffer Type = 6 (unsigned char)

Bytes per Point = 1

Buffer Type = 6 (unsigned char)

Bytes per Point = 1

Waveform Header 1

140 bytes

Number of Waveform Buffers = 1

Default Chapter4
