Keysight Technologies P Series Service Guide

Repair Guide 6
Keysight N8262A Service Guide 107
Mother board, measurement board, and PPMC board disassembly
instructions
Instructions Visual
Use a T10 Torx screwdriver bit to remove the
four captive screws and remove the bumper
foot.
Note:
You need to remove the bumper foot first before
removing the cover.
– Use a T20 Torx screwdriver bit to remove the
four screws located at the rear panel.
– Pull and remove the cover at the rear panel.
See the figure on the right column for more
details.
