6 Repair Guide
102 Keysight N8262A Service Guide
Calibrator disassembly instructions
Instructions Visual
Use a 10 Torx screwdriver bit to remove the
four captive screws and remove the bottom
feet.
Note:
You need to remove the bumper foot first before
removing the cover.
– Use a T20 Torx screwdriver bit to remove
four screws located at the rear panel.
– Pull and remove the cover at the rear panel.
See the figure to the right for more details.
