6 Repair Guide
104 Keysight N8262A Service Guide
Power supply disassembly instructions
Instructions Visual
Use a T10 Torx screwdriver bit to remove the
four captive screws and remove the bumper
foot.
Note:
You need to remove the bottom feet first before
removing the cover.
– Use a T20 Torx screwdriver bit to remove
four screws located at the rear panel.
– Pull and remove the cover at the rear panel.
See the figure to the right for more details.
To Next Page
