Specifications 1
Keysight N8262A Service Guide 35
Rear panel inputs/outputs
Remote programming
Measurement speed
10/100 BaseT LAN Interface allow communication with an external controller.
Ground Binding post, accepts 4 mm plug or bare-wire connection.
Line power
Input voltage range
100 to 120 V ± 10%
220 to 240 V ± 10%
Input frequency range
50 to 60 Hz ± 10% (all voltages)
400 to 440 Hz ± 10% (100 to 120 V)
Power requirement 50 VA (30 watts) not exceeding 75 VA (50 watts)
A 3 kV, 100 kHz transient in the power line may cause the instrument to
reset.
Interface 10/100 BaseT LAN interface
Command language SCPI standard interface commands
Measurement speed via remote interface
1500 readings per second
