Keysight Technologies P Series Service Guide

1 Specifications
28 Keysight N8262A Service Guide
P-Series Modular Power Meter and Sensor
Key system specifications and characteristics
Maximum sampling rate 100 Msamples/sec, continuous sampling
Video band width

30 MHz
Single shot bandwid th

30 MHz
Rise time and fall time

13 ns (for frequencies

500 MHz)
[a]
, see Figure 1-1
[a] Specification applies only when the Off video bandwidth is selected.
Minimum pulse width
50 ns
[b]
[b] The Minimum Pulse Width is the recommended minimum pulse width viewable on the power meter, where power
measurements are meaningful and accurate, but not warranted.
Overshoot

5%
[a]
Average power measurement
accuracy
N1921A:

±0.2 dB or ±4.5%
[c]
N1922A:

±0.3 dB or ±6.7%
[c] Specification is valid over –15 to +12 dBm, and a frequency range 0.5 to 10 GHz, DUT Max. SWR <1.27 for the
N1921A, and a frequency range 0.5 to 40 GHz, DUT Max. SWR <1.2 for the N1922A. Averaging set to 32, in Free
Run mode.
Dynamic range
–35 dBm to +20 dBm (>500 MHz)
–30 dBm to +20 dBm (50 MHz to 500 MHz)
Maximum capture length 1 second
Maximum pulse repetition rate 10 MHz (based on 10 samples per period)
