Specifications 1
Keysight N8262A Service Guide 31
External TTL trigger output Low to high transition on trigger event
High >2.4 V
Low <0.7 V
Latency
[c]
30 ns ± 10 ns
Impedance 50

Jitter

5 ns RMS
Trigger delay
Delay range ±1.0 s, maximum
Delay resolution 1% of delay setting, 10 ns maximum
Trigger hold-off
Range 1
 s to 400 ns
Resolution 1% of selected value (to a minimum of 10 ns)
Trigger level threshold hysteresis
Range ±3 dB
Resolution 0.05 dB
[a] Internal trigger latency is defined as the delay between the applied RF crossing the trigger level and the meter
switching into the triggered state.
[b] External trigger latency is defined as the delay between the applied trigger crossing the trigger level and the meter
switching into the triggered state.
[c] External trigger output latency is defined as the delay between the meter entering the triggered state and the
output signal switching.
Trigger
