Parameter Typical Return
POSitive|NEGative, *RSTPOSitive POS or NEG
Set current slope to negative (falling edge): TRIG:ACQ:CURR:SLOP NEG
Set voltage slope to negative (falling edge): TRIG:ACQ:VOLT:SLOP NEG
TRIGger:ACQuire:INDices[:DATA]?
Returns the indices into the acquired data where triggers were captured during the acquisition. The
number of indices returned is the same as the value returned by TRIGger:ACQuire:INDices:COUNt?
Parameter Typical Return
(none) <time>
Returns the number of indices: TRIG:ACQ:IND?
TRIGger:ACQuire:INDices:COUNt?
Returns the number of triggers captured during the acquisition.
Parameter Typical Return
(none) <time>
Return the number of triggers: TRIG:ACQ:IND:COUN?
TRIGger:ACQuire:TOUTput[:ENABle] 0|OFF|1|ON
TRIGger:ACQuire:TOUTput[:ENABle]?
Enables measurement triggers to be sent to a digital port pin. The digital port pin must be configured
as trigger output before it can be used as a trigger source (see External Trigger I/O).
Parameter Typical Return
0|OFF|1|ON, *RST OFF 0or1
Enable sending measurement triggers to digital pins: TRIG:ACQ:TOUTON
TRIGger:ACQuire:SOURce <source>
TRIGger:ACQuire:SOURce?
Selects the trigger source for the acquisition system:
BUS Selects a remote interface trigger command.
CURRent1 Selects an output current level.
EXTernal Selects ALL digital port pins that have been configured as trigger sources.
PIN<1-7> Selects a digital port pin configured as a trigger input.
TRANsient1 Selects the transient system as the trigger source.
VOLTage1 Selects an output voltage level.
Keysight RP7900 Series Operating and Service Guide 233
5 SCPI Programming Reference
