The following table describes the Questionable2 assignments.
Bit Bit Name Decimal
Value
Definition
0 not used not used 0 is returned
1 IPK+ 2 Output is in positive peak current limit
2 IPK- 4 Output is in negative peak current limit
3 CSF 8 A current sharing fault has occurred
4 MSP 16 Output is disabled by a master/slave protection
5 SDP 32 Output is disabled by a Safety DisconnectSystem protection
6 UV 64 An under-voltage protection has occurred.
7-15 not used not used 0 is returned
Standard Event Status Group
These registers are programmed by Common commands. The group consists of an Event and Enable
register. The Standard Event event register latches events relating to communication status. It is a
read-only register that is cleared when read. The Standard Event enable register functions similarly
to the enable registers of the Operation and Questionable status groups. Refer to Status Diagram.
The following table describes the Standard Event Status register bit assignments.
Bit Bit Name Decimal
Value
Definition
0 Operation
Complete
1 All commands before and including *OPC have been executed.
1 not used not used 0 is returned
2 Query Error 4 The instrument tried to read the output buffer but itwas empty,
a newcommand line was received before a previous query has been
read, or both the input and output buffers are full.
3 Device- specific Error 8 A device-specific error, including a self-test error, calibration error or
other device-specific error occurred. Error Messages
4 Execution Error 16 An execution error occurred. Error Messages
5 Command 32 A command syntax error occurred. Error Messages
6 not used not used 0 is returned
7 Power On 128 Power has been cycled since the last time the event register was read
or cleared.
5 SCPI Programming Reference
242 Keysight RP7900 Series Operating and Service Guide
