Keysight N9927-90001 User’s Guide 163
SA (Spectrum Analyzer) Mode
SA Mode Settings
To select Listen Time:
—Press Meas Setup 4
—Then Listen Time
— Enter a value using the numeric keypad, arrows, or the rotary knob.
Then select a multiplier key. Learn about multiplier abbreviations.
Volume Control
To increase or decrease the Volume of the demodulated signal:
—Press Meas Setup 4
—Then Volume
— Enter a value in percent between 0 and 100 (loudest) using the numeric
keypad, arrows, or the rotary knob.
— Volume can also be changed and easily muted from the System
menu.
Learn more in “How to set the FieldFox Volume Control” on page 512.
Demod ON and OFF
To quickly stop the audio demodulation and perform only the normal SA
sweeps, select the following:
—Press Meas Setup 4
—Then Demod ON OFF
Independent Source/Tracking Generator
This feature may require an option. For a comprehensive list, view the FieldFox
Configuration Guide at:
http://literature.cdn.keysight.com/litweb/pdf/5990-9836EN.pdf
A tracking generator, a popular option with Spectrum Analyzers, is a source
which always tracks the SA receiver.
Like a traditional tracking generator, the Independent Source feature can set
the internal FieldFox source to track the SA receiver frequency range. It can
also set the internal source to a CW frequency that is independent of the SA
frequency.
Independent Source can be enabled ONLY when the FieldFox is in SA mode.
To view the internal source, you must connect a cable or device between the
RF Output connector and the RF Input connector.
For best results, when using the independent source feature, InstAlign and
the battery saver features should be turned off. Refer to “How to Access
Individual Alignments” on page 184 and “Preferences” on page 515.
