316 Keysight N9927-90001 User’s Guide
Interference Analyzer (SA Mode) – Option 236
Record/Playback (SA Option)
— AutoSession is an auto-generated name for sessions. 02 is the
auto-generated number, incremented with each new session. The name
can be changed using Manage Sessions. Learn more in “Manage Sessions”
on page 321.
— 92/95
is the current and total trace number: currently trace is 92 of 95 total
traces.
— state 4/5
is the current and total state tag or user tag number: 4 of 5 total
tags.
— *
(Asterisk) indicates that a state has changed. # (Pound) indicates that a
User Tag has been inserted.
— Sep.22..
. is the date and time of recording.
When GPS is enabled`, the current location and elevation are annotated at the
bottom of the playback display. Learn more in “GNSS (GPS+) and GPS” on
page 526.
— Is the sweep in HOLD? (upper-left annotation)
— Is Recording or Playback Paused? (mid-left annotation)
—Is the Record or Playback Interval set too long? (Configuration settings.)
How to Record a Session
—Press Trace 6
—Then Record Playback
— SA Only: Optionally set resolution (points). Learn how in “Points ” on
page 177. This can NOT be changed after a session is opened.
— Then either:
— New Session
OR
— Recall Session
then Open and select a session.
—Then Recorder Player
—Then Record
REC is displayed in the left of screen graticules.
During recording, choose from the following:
— Pause Resume
Temporarily halts recording until pressed again. The
incoming trace continues to sweep. Press again to continue recording.
— Stop
Immediately stops recording. Then choose from the following:
If Recording or Playback is not occurring when you think it should, check
the following:
