Keysight N9927-90001 User’s Guide 411
Channel Scanner (Option 312)
How to Set Up Channel Scanner
Press Scale/Amptd
Then one of the following:
— Red Limit
to set the power level and color scale for high power
channels.
— Blue Limit
to set the power level and color scale for low power
channels.
— Others: Scale
, Ref Level, RF Atten, etcetera as desired.
4. Enable Data Logging
and set the Record Settings.
— Record
or
— Play
or
— View
— To set the Record Settings—choose:
— Meas Interval
— Interval Time
— Time Interval
— Distance Interval and or
— Auto Save
(default is On)
5. Then select the User Folder and save to *.KML or *.CSV file, Save-Recall
Rec-Playback:
— Then User Folder Def System
— Def – Sets the default User Folder path:
——List files (*.csv and *.kml) are save-recalled to:
"CurrentDevice\ChannelScanner\ChannelS
canner\RecordPlayback\"
——Record-Play files are save-recalled to:
"CurrentDevice\ChannelScanner\ChannelS
canner\RecordPlayback\"
Or
— System
– Sets the User Folder to the user defined system
folder path/name:
——List files are save to-from
"CurrentDevice\<UserSelectedFolder>\"
——Record-Play files are save-recalled to:
"CurrentDevice\<UserSelectedFolder>\"
Refer to Chapter 28, “File Management.”
