Keysight N9927-90001 User’s Guide 447
Noise Figure Mode (Option 356 – CPU2 Only)
How to Define a Noise Figure Measurement
——Save DUT Table Opens a Create a filename menu
of softkeys to enter a DUT table filename and
then to save the file.
——Recall DUT Table
Opens a Select a file menu of
softkeys to enter a DUT table filename to recall.
——Storage Device [Internal]
Opens a set of softkeys
to select where your DUT table is saved.
Then choose Internal
, SD Card, or USB.
— Back
to return to previous menu.
— Preamp
Sets the DUT Mode to either Spot (default) or
Table.
Then choose:
——Preamp Mode
Set to Spot (default) or to Table.
For Preamp MODE Spot choose:
——Preamp Spot Values
(Only active when DUT
Mode = Spot).
Refer to similar “DUT Spot Values
(Only active
when DUT Mode = Spot).” on page 446.
——Back
to return to previous menu.
——Preamp Table Edit/Save/Recall
(Only active
when Preamp Mode = Table).
Refer to similar “DUT Table Edit/Save/Recall
(Only active when DUT Mode = Table).” on
page 446.
——Back
to return to previous menu.
— Uncert Contributions
Opens a menu of uncertainty
contribution softkeys.
Then choose:
——Jitter Uncert.
Enable/disable the Jitter
Uncertainty.
——ENR Uncert.
Enable/disable the ENR
Uncertainty.
——Mismatch Uncert.
Enable/disable the Mismatch
Uncertainty.
